ICS-G7748A/G7750A/G7752A/G7848A/G7850A/G7852A Serisi Yönetilebilir Modüler Switchler için 4G-port Ethernet Modülleri
Moxa ICS-G7848A/G7850A/G7852A (Layer 3) ve Moxa ICS-G7748A/G7750A/G7752A (Layer 2) Serileri için Moxa IM-G7000A Hot swap destekli, endüstriyel Gigabit Ethernet arayüz modülleridir. IM-G7000A interface modüllerinin esnekliği sayesinde ICS Serisi switchlerde 48 porta kadar Bakır ya da SFP interface sağlanabilir.
Interface
Fiber Ports 100/1000BaseSFP slot
RJ45 Ports 10/100/1000BaseT(X) auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection
PoE+ Ports 10/100/1000BaseT(X) auto negotiation speed, compliant with IEEE 802.3af/at high power mode up to 36 W
LED Indicators STAT, 10/100/1000 for TP port, 100/1000 for fiber port
Hot Swap Button Push this button prior to swapping IM-G7000A modules
Power Requirements
IM-G7000A-4GTX: 4.1 W
IM-G7000A-4GSFP: 3.3 W
IM-G7000A-4PoE: 6.07 W (without PD power consumption)
Note
The IM-G7000A-4PoE must be connected to a 48 VDC external power supply to provide power to PoE devices.
Physical Characteristics
Housing IP30 protection
Dimensions 28.8 x 174.7 x 166.8 mm (1.13 x 6.88 x 6.57 in)
Weight 220 g
MTBF (mean time between failures)
Time IM-G7000A-4GTX: 1,569,520 hrs
IM-G7000A-4GSFP: 1,544,084 hrs
IM-G7000A-4PoE: 394,348 hrs
Warranty
Warranty Period 5 years
Details See www.moxa.com/warranty
Uygun Modeller
IM-G7000A-4GTX
Gigabit Ethernet interface module with 4 10/100/1000BaseT(X) ports, 0 to 60°C operating temperature
IM-G7000A-4GSFP
Gigabit Ethernet interface module with 4 100/1000BaseSFP slots, 0 to 60°C operating temperature
IM-G7000A-4PoE
Gigabit Ethernet PoE+ interface module with 4 10/100/1000BaseT(X) ports, -10 to 60°C operating temperature
